JiuTu Technology Co.,Ltd

OCA Bubble Remover Machine

OCA Bubble Remover Machine

$8,800.00 USD
$9,800.00 USD $8,800.00 USD
Sale Ausverkauft
Versand wird beim Checkout berechnet
OCA Bubble Remover Machine

Main Features :

1 This equipment is high pressure heating ITO+CG, FILM+CG, CTP+LCD module defoaming machine.--OCA Bubble Remover Machine

2.This equipment is suitable for the process of defoaming it after hard-hard bonding (CG bonding) or assembly (CTP+LCD) process.--OCA Bubble Remover Machine

3. This equipment is for simultaneous temperature rise and boost.

1.1 Equipment introduction and purpose
1.1.1 : This equipment is a segmented high-pressure defoaming machine (bubble remover machine).--OCA Bubble Remover Machine
It’s widely used for electronics and optoelectronics industry, Removing air bubbles and vacuum bubbles--OCA Bubble Remover Machine
after vacuum lamination with optical glue SCA and OCA glue. Effectively improve product yield.--OCA Bubble Remover Machine

1.1.2 : Segmented high-pressure , both temperature and pressure can be adjusted by different segmented based on the actual product, max temperature is 80 degree , max pressure is 0.8Mpa

1.2 Equipment technical parameters
1.2.1 machine size :
length 1580mm width 1030mm Height 1700mm
1.2.2 Inner chamber size : Diameter 600mm Depth 900mm
1.2.3 Gross weight about 500KG
1.2.3 Safety pressure :0.8mpa
1.2.4 Volatge AC 220V

1.3 Equipment Installation
1.3.1 Power supply, to ensure the power supply demand AC220V 2000W.
1.3.2 Air supply to ensure the air pressure supply 0.8mpa.
1.3.3 Machine installation, 12 casters adjust the horizontal state, and the casters are locked and fixed.--OCA Bubble Remover Machine

1.4 Equipment maintenance
1.4.1 Circuit maintenance: check whether the circuit is loose or abnormal every 15 working days, Appropriate reinforcement if there is any abnormality

1.4.2 Air circuit maintenance; every 15 working days, check the air circuit for air leakage from the air pipe joints.--OCA Bubble Remover Machine
If there is any abnormality, repair and reinforce or replace it in time

1.4.3 Fan maintenance; manual debugging every 15 working days to check whether the fan is running abnormally, and
replace it in time if there is any abnormality

1.4.4 Add lubricating oil; manually open the door cover of the defoaming machine every 15 working days and add
lubricating oil to the movable place
OCA Bubble Remover Machine

P/N
9TU-M061
Model
56 inch Big Autoclave LCD Bubble Remover Machine
Function
Remove Rest Bubbles after Lamination for LCD Screen Refurbishing ,ok for big lcd screens
Application
Fit for All Smart Phone LCD Screen Under 37 inch , including martphone, iPad, Notebook, computer, ok for TV ,LED ,Advertise screen
, Bus Screen, Airplane screen, Car DVD Screen, industrial device screen repair
Air Compressor
Needed (Can share the same air compressor with OCA Vacuum Laminator )
Vacuum Pump
No Need
Voltage
220V /500W
Feature 1
New Design Door , More Safety and Convenient Without Screw Lock
Feature 2
Save time ,ok to put more then 100pcs LCD Screens together
Time
15--25 Mins , can adjust by yourself
Warranty
2 years
Packing
Customized Box for Shipping
After-service
Professional technical support will be provided until you can do with perfect results
Fast Delivery
Ship within 2 working days after payment is done
GW
850 KG
Autoclave Size
80 x 120 cm

Vollständige Details anzeigen

Frequently Asked Questions

What is the main function of the OCA Bubble Remover Machine?
The OCA Bubble Remover Machine is designed to remove air bubbles and vacuum bubbles after lamination with optical and OCA glue, improving product yield in electronics manufacturing.
Is the OCA Bubble Remover Machine suitable for large LCD screens?
Yes, the OCA Bubble Remover Machine is capable of handling large LCD screens, including those over 37 inches, making it ideal for big LCD panel defoaming and refurbishing applications.
What are the technical specifications of the OCA Bubble Remover Machine?
The machine measures 1580mm x 1030mm x 1700mm, with an inner chamber diameter of 600mm and depth of 900mm. It operates at a maximum temperature of 80°C, maximum pressure of 0.8 Mpa, and weighs about 500kg.
What maintenance is required to keep the OCA Bubble Remover Machine running smoothly?
Regular maintenance includes checking circuits and air leaks every 15 working days, inspecting fan operation, and lubricating moving parts to ensure optimal performance and safety.
How quickly can the OCA Bubble Remover Machine process LCD screens?
The machine can process screens in approximately 15-25 minutes, with adjustable settings to suit different film types and sizes, saving time and increasing efficiency in screen refurbishment.
